brass ball valve for gas DN15 - 1/2" inch GK14 female thread

GK14000003
quantity (pcs.):
10.00€ * 11.60€ incl. VAT
*Price plus VAT and shipping costs

Delivery time: 1-2 working days

datasheet 3D model
All the information quoted in these resistance tables is based on industrial experience and the data of our material and compound manufacturers. NieRuf GmbH makes no guarantee, however, as to the correctness and completeness of this informations.

If materials are rated as ''limited suitability'', the time of impact has to be considered. At a long period of impact these materials can be heavily attacked or even destroyed. There- fore these parts are rated as wear parts and are not included in the standard warranty conditions.
Questions about the article?
Our colleague Meiko Holzinger will be happy to help:
Tel: +497143/9666-904
E-Mail: holzinger@nieruf.de
technical details
brass ball valve for gas DN15 - 1/2" inch GK14 female thread
brass ball valve for gas DN15 - 1/2" inch full port design seal made of 2 Viton O-rings for gas DVGW-Gas
diameter: DN15 - 1/2" inch
connection: female thread
Seal steam: 2 Viton O-rings
media: gas DVGW-Gas
temperature: gas -20°C up to +60°C
max. pressure: PN65
design: full port design
body material: CW617N nickel plated
ball material: CW617N chrome plated
ball seal: PTFE
length: 75mm
actuator: lever handle made of steel zinc coated with yellow plastic cover
installation position: any position
product description: This high quality brass gas ball valve with heavy design has a Certification-gas acc. to DIN EN 331 and DIN DVGW NG-4312CP0230
brass ball valve for gas DN15 - 1/2" inch GK14 female thread

Quickly and easily transfer the specification of our valves into your tender text or specification.
Just copy the text box below and paste it into your tender.

brass ball valve for gas DN15 - 1/2" inch GK14 female thread
