The right proportional valve for your areas of use



Product Configurator:

Close filters
  •
  •
  •
  •
  •
  •
/

No results were found for the filter!
dual plate check valve DN200 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 3/8" inch stainless steel 1.4404 FKM/FPM 0 - 10 volt

Article No.: ED01000002

proportional motorised valve 3/8" inch made of stainless steel to control the flow in the system up to 2700 l/h with an setpoint of 0 - 10 volt FKM/FPM
diameter: 3/8" inch
connection: female thread BSP-P
KVS: 2700 l/h
setpoint: 0 - 10 volt
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: at stock

Express shipping:

datasheet
dual plate check valve DN300 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 1/2" inch stainless steel 1.4404 FKM/FPM 4 - 20 mA

Article No.: ED01000103

proportional motorised valve 1/2" inch made of stainless steel to control the flow in the system up to 3800 l/h with an setpoint of 4 - 20 mA FKM/FPM
diameter: 1/2" inch
connection: female thread BSP-P
KVS: 3800 l/h
setpoint: 4 - 20 mA
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: at stock

Express shipping:

datasheet
dual plate check valve DN250 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 1/2" inch stainless steel 1.4404 FKM/FPM 0 - 10 volt

Article No.: ED01000003

proportional motorised valve 1/2" inch made of stainless steel to control the flow in the system up to 3800 l/h with an setpoint of 0 - 10 volt FKM/FPM
diameter: 1/2" inch
connection: female thread BSP-P
KVS: 3800 l/h
setpoint: 0 - 10 volt
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: 3 - 4 Weeks

datasheet
dual plate check valve DN125 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 3/4" inch stainless steel 1.4404 FKM/FPM 0 - 10 volt

Article No.: ED01000004

proportional motorised valve 3/4" inch made of stainless steel to control the flow in the system up to 6000 l/h with an setpoint of 0 - 10 volt FKM/FPM
diameter: 3/4" inch
connection: female thread BSP-P
KVS: 6000 l/h
setpoint: 0 - 10 volt
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: 3 - 4 Weeks

datasheet
dual plate check valve DN350 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 3/8" inch stainless steel 1.4404 FKM/FPM 4 - 20 mA

Article No.: ED01000102

proportional motorised valve 3/8" inch made of stainless steel to control the flow in the system up to 2700 l/h with an setpoint of 4 - 20 mA FKM/FPM
diameter: 3/8" inch
connection: female thread BSP-P
KVS: 2700 l/h
setpoint: 4 - 20 mA
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: 3 - 4 Weeks

datasheet
dual plate check valve DN450 DR03 ANSI 150 stainless steel 1.4408 EPDM 2
proportional motorised valve ED01 3/4" inch stainless steel 1.4404 FKM/FPM 4 - 20 mA

Article No.: ED01000104

proportional motorised valve 3/4" inch made of stainless steel to control the flow in the system up to 6000 l/h with an setpoint of 4 - 20 mA FKM/FPM
diameter: 3/4" inch
connection: female thread BSP-P
KVS: 6000 l/h
setpoint: 4 - 20 mA
seal: FKM/FPM
368.10€ *
438.04€ incl. VAT

Delivery time: 3 - 4 Weeks

datasheet

Proportional valves below are also called flow regulator valves or motor valves, they are used in pipe systems, machine and plant construction, process engineering, packaging machines, and in the food industry, for example for filling systems and compressed air applications. This valve type is used wherever a liquid or gaseous medium, or even steam, has to be smoothly regulated. Many valves can only be completely closed or opened. The proportional valve has a large advantage here because it can be opened and closed proportionally by an electronic signal and thus has dozens of variable degrees of opening. Additionally, the system can be adjusted during running operation. Thanks to these properties, this proportional valve is excellent for dosing processes.

High quality motor valves with smooth opening degree settings!

We offer motor valves of type ED01 with very long life, thanks to the high-quality stainless steel 1.4404. The so-called control head can be rotated 360° and as a result is very flexible for the installation. The controls are either via a voltage of 0-10 Volt or a current of 4-20mA. Thanks to the unique design, there is a constant media separation between the valve casing and the motorised drive, and also there is a low water-shock design and therefore it is suitable for steam applications as well. The valve also has an integrated LED as a status display. Thanks to the angle seat design, the motor valves have excellent flow values (KVs) and also retain the set valve position if there is a voltage / current failure. The motor valve can even be used in a vacuum and is suitable for viscose media, for more information please see the datasheet. We will be happy to help you select your motor valve.
