Globe valves
High-quality & maintenance-free globe valves with bellows!
Globe valves are usually used in applications, where a medium needs to be regulated or shut off. Due to its construction, the option regulation cone very precisely regulates the flow of the medium within the pipeline system. The operation of the bellows globe valve happens manually, using a hand wheel, but automation is optional. The hand lever or motor moves a spindle unit, on which both the bellows and the cone are fixed.
Flange-Globe valve DN 80 in straight through with bellow flange acc. DIN EN 1092 material grey cast iron DN-JL1040 with Isolation plug
diameter:
DN 80
flange:
flange acc. DIN EN 1092
plug:
Isolation plug
pressure range:
max. 16 bar depending on operating temperature
length:
acc DIN EN 558 series 1
Globe valve DN 250 Isolation plug in straight through with bellow flange acc. DIN EN 1092 material stainless steel 1.4408
diameter:
DN 250
flange:
flange acc. DIN EN 1092
plug:
Isolation plug
pressure range:
max. 16 bar depending on operating temperature
length:
acc DIN EN 558 series 1
Flange-Globe valve DN 150 in straight through with bellow flange acc. DIN EN 1092 material grey cast iron DN-JL1040 with regulation cone
diameter:
DN 150
flange:
flange acc. DIN EN 1092
plug:
regulation cone
pressure range:
max. 16 bar depending on operating temperature
length:
acc DIN EN 558 series 1
Globe valve DN 25 PN40 Isolation plug in straight through with bellow flange acc. DIN EN 1092 Material stainless steel 1.4408
diameter:
DN 25
flange:
flange acc. DIN EN 1092
plug:
Isolation plug
pressure range:
max. 40 bar depending on operating temperature
length:
acc DIN EN 558 series 1
