Pressure reducing valves
Get your pressure reducing valve directly from the expert
Pressure reducing valves are being used in pipeline systems in order to equalize different pressures at the incoming side of the pressure reducing valve, and not to exceed a specific pressure at the outgoing side of the valve. By using a pressure regulator, you can avoid having a supply pressure within the pipeline system or the facility that is too high. When using a pressure regulator within sanitary facilities or building technology, the pressure regulator needs to be DVGW approved. Pressure reducing valves can be safeguarded by using a safety valve at the outgoing side. We have all established seals, slange, female- and male threads and pressure ranges in stock. Please do not hesitate to contact us for individual consulting, and feel free to order your pressure reducing valve right from our online shop.
steam pressure reducing valve DN25 made of stainless steel 1.4408 flange acc. to DIN EN 1092-1 seal PTFE | backside seals FKM for saturated steam, set pressure 1.0 - 6.0 bar
diameter:
DN25
connection:
flange acc. to DIN EN 1092-1
range of adjustment:
1.0 - 6.0 bar
material:
stainless steel 1.4408
seal:
PTFE | backside seals FKM
pressure-control-valve 1" Inch made of plastic polyamid female thread seal NBR for air, set pressure 0.5 - 8.0 bar
diameter:
1" Inch
connection:
female thread
range of adjustment:
0.5 - 8.0 bar
material:
plastic polyamid
seal:
NBR
pressure-control-valve 3/4" Inch made of plastic polyamid female thread seal NBR for air, set pressure 0.5 - 8.0 bar
diameter:
3/4" Inch
connection:
female thread
range of adjustment:
0.5 - 8.0 bar
material:
plastic polyamid
seal:
NBR
steam pressure reducing valve DN15 made of stainless steel 1.4408 flange acc. to DIN EN 1092-1 seal PTFE | backside seals FKM for saturated steam, set pressure 1.0 - 6.0 bar
diameter:
DN15
connection:
flange acc. to DIN EN 1092-1
range of adjustment:
1.0 - 6.0 bar
material:
stainless steel 1.4408
seal:
PTFE | backside seals FKM
