Reliable container flow indicator for visual monitoring!

Within closed pipework or pressure tanks, it can be helpful to install sight flow indicators to visually monitor and control the media. The sight flow indicator allows you to monitor the direction of flow, and to check for foreign particles, which could damage the machine or the application. That makes the sight flow indicator perfect for visual monitoring, for example in a round, oval or rectangular shape. The construction resembles DIN 28120 or DIN 128121, which allows for easy welding. NieRuf is your partner for high-quality sight flow indicators.

Filter

Product finder

sight flow indicator DN80 - 3" Inch aus stainless steel 1.4404 / AISI 316L to be welded directly to tank acc. DIN 11851 Glas borosilicate glass 10,0 bar

diameter:

DN80 - 3" Inch

connection:

to be welded directly to tank acc. DIN 11851

seal:

NBR

design:

for welding

max. working pressure:

10,0 bar

NieRuf-Exchange
€132.80*

€158.03 VAT included.

Delivery time: 3 - 5 working days

female thread sight flow indicator DN8 - 1/4" Inch Typ GS01 grey cast iron GG25 soda lime glass graphit max 16 bar

diameter:

DN8 - 1/4" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€103.70*

€123.40 VAT included.

Delivery time: in stock

Express delivery:

female thread sight flow indicator DN10 - 3/8" Inch Typ GS01 grey cast iron GG25 soda lime glass graphit max 16 bar

diameter:

DN10 - 3/8" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€103.70*

€123.40 VAT included.

Delivery time: in stock

Express delivery:

flow-through sight flow indicator 1 1/4" borosilicate glass Typ GS03 borosilicate glass graphit max 16 bar

diameter:

DN32 - 1 1/4" inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

NieRuf-Exchange
Certified
€468.00*

€556.92 VAT included.

Delivery time: in stock

Express delivery:

flow-through sight flow indicator DN8 - 1/4" Inch Typ GS03 stainless steel soda lime glass graphit max 16 bar

diameter:

DN8 - 1/4" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

NieRuf-Exchange
Certified
€198.80*

€236.57 VAT included.

Delivery time: in stock

Express delivery:

sight flow indicator DN65 - 2 1/2" Inch aus stainless steel 1.4404 / AISI 316L to be welded directly to tank acc. DIN 11851 Glas borosilicate glass 10,0 bar

diameter:

DN65 - 2 1/2" Inch

connection:

to be welded directly to tank acc. DIN 11851

seal:

NBR

design:

for welding

max. working pressure:

10,0 bar

NieRuf-Exchange
€99.10*

€117.93 VAT included.

Delivery time: in stock

Express delivery:

female thread sight flow indicator DN20 - 3/4" Inch Typ GS01 grey cast iron GG25 soda lime glass graphit max 16 bar

diameter:

DN20 - 3/4" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€138.30*

€164.58 VAT included.

Delivery time: in stock

Express delivery:

sight flow indicator DN50 - 2" Inch aus stainless steel 1.4404 / AISI 316L to be welded directly to tank acc. DIN 11851 Glas borosilicate glass 10,0 bar

diameter:

DN50 - 2" Inch

connection:

to be welded directly to tank acc. DIN 11851

seal:

NBR

design:

for welding

max. working pressure:

10,0 bar

NieRuf-Exchange
€87.80*

€104.48 VAT included.

Delivery time: in stock

Express delivery:

flow-through sight flow indicator DN50 - 2" Inch Typ GS03 stainless steel soda lime glass graphit max 16 bar

diameter:

DN50 - 2" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

NieRuf-Exchange
Certified
€1,005.20*

€1,196.19 VAT included.

Delivery time: in stock

Express delivery:

Sight glass fitting DN50 - 2" Inch aus stainless steel 1.4571 to be welded directly to tank Glas borosilicate glass 2,5bar

diameter:

DN50 - 2" Inch

connection:

to be welded directly to tank

seal:

C4400

design:

to be welded directly to tank

max. working pressure:

2,5bar

NieRuf-Exchange
€232.20*

€276.32 VAT included.

Delivery time: in stock

Express delivery:

flow-through sight flow indicator DN10 - 3/8" Inch Typ GS03 stainless steel soda lime glass graphit max 16 bar

diameter:

DN10 - 3/8" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

NieRuf-Exchange
Certified
€198.80*

€236.57 VAT included.

Delivery time: in stock

Express delivery:

Sight glass fitting DN80 - 3" Inch aus stainless steel 1.4571 to be welded directly to tank Glas borosilicate glass 2,5bar

diameter:

DN80 - 3" Inch

connection:

to be welded directly to tank

seal:

C4400

design:

to be welded directly to tank

max. working pressure:

2,5bar

NieRuf-Exchange
€302.40*

€359.86 VAT included.

Delivery time: in stock

Express delivery:

sight flow indicator 1 1/2" design with disc Typ GS02 borosilicate glass graphit max 16 bar

diameter:

DN40 - 1 1/2" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€456.50*

€543.24 VAT included.

Delivery time: 2 - 3 weeks

female thread sight flow indicator 2" grey cast iron GG25 Typ GS01 graphit max 16 bar design with PTFE-spinner

diameter:

DN50 - 2" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€401.80*

€478.14 VAT included.

Delivery time: 2 - 3 weeks

flange sight flow indicator DN200 soda lime glass Typ FS01 grey cast iron GG25 graphit max 10 bar design with PTFE-spinner

diameter:

DN200 - 8" Inch

connection:

flange PN16

seal:

graphit

design:

straightway form

max. working pressure:

max 10 bar

Certified
€2,491.20*

€2,964.53 VAT included.

Delivery time: 2 - 3 weeks

female thread sight flow indicator DN50 - 2" Inch grey cast iron GG25 Typ GS01 soda lime glass graphit max 16 bar design with disc

diameter:

DN50 - 2" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€332.70*

€395.91 VAT included.

Delivery time: 2 - 3 weeks

flange sight flow indicator DN200 design with disc Typ FS01 grey cast iron GG25 borosilicate glass graphit max 16 bar

diameter:

DN200 - 8" Inch

connection:

flange PN16

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€2,383.20*

€2,836.01 VAT included.

Delivery time: 2 - 3 weeks

flange sight flow indicator DN32 soda lime glass Typ FS01 grey cast iron GG25 graphit max 16 bar design with PTFE-spinner

diameter:

DN32 - 1 1/4" inch

connection:

flange PN16

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€324.00*

€385.56 VAT included.

Delivery time: 2 - 3 weeks

Sight glass fitting DN200 - 8" Inch aus stainless steel 1.4571 to be welded directly to tank Glas borosilicate glass 0,0 bar pressureless

diameter:

DN200 - 8" Inch

connection:

to be welded directly to tank

seal:

C4400

design:

to be welded directly to tank

max. working pressure:

0,0 bar

NieRuf-Exchange
€664.20*

€790.40 VAT included.

Delivery time: 3 - 5 working days

flange sight flow indicator DN150 casti iron disc Typ FS02 borosilicate glass max 16 bar

diameter:

DN150 - 6" Inch

connection:

flange PN16

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€2,232.00*

€2,656.08 VAT included.

Delivery time: 2 - 3 weeks

flange sight flow indicator DN32 Typ FS02 GS - C25 soda lime glass graphit max 16 bar

diameter:

DN32 - 1 1/4" inch

connection:

flange PN16

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€332.70*

€395.91 VAT included.

Delivery time: 2 - 3 weeks

female thread sight flow indicator 1" design with PTFE-spinner Typ GS01 grey cast iron GG25 borosilicate glass graphit max 16 bar

diameter:

DN25 - 1" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€283.70*

€337.60 VAT included.

Delivery time: 2 - 3 weeks

flow-through sight flow indicator 1 1/2" soda lime glass Typ GS03 graphit max 16 bar design with PTFE-spinner

diameter:

DN40 - 1 1/2" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€642.30*

€764.34 VAT included.

Delivery time: 2 - 3 weeks

female thread sight flow indicator 1/4" design with disc Typ GS01 grey cast iron GG25 borosilicate glass graphit max 16 bar

diameter:

DN8 - 1/4" Inch

connection:

female thread

seal:

graphit

design:

straightway form

max. working pressure:

max 16 bar

Certified
€201.60*

€239.90 VAT included.

Delivery time: 2 - 3 weeks

Flange sight flow indicators from high-quality stainless steel, with flange or threaded conncetion

The flange sight flow indicator has to comply with a variety of guidelines, norms and requirements. We provide DIN 3237 valves from stock, whether you need borosilicate glass DIN 7080 or soda lime glass DIN 8902. The choice of the glass depends on the temperature or the media and the surrounding, as well as the pressure range of the media. Depending on the media, the sight flow indicator will be made from stainless steel (1.4408/V4A), brass or cast steel. Depending on the pipeline system, we provide sight flow indicators with flange or thread connection in sizes DN15, DN20 up to DN65 and DN80 up to DN200, or, for fast assembly with a female thread from ¼“ to ½“ and up to 2“ from stock. Please contact us for irregular sizes and special design.

Sight flow indicators with flap or PTFE spinner at low cost

Sight flow indicators are usually built into a pipeline system as flange sight flow indicators. Visual monitoring can be made easier by using a flap or a PTFE spinner, which move when there is flow. Container flow indicators however, are usually used within closed containers such as boilers, oil tanks and silos. This enables you to visually monitor the filling level. Please contact us if you need any help finding the right sight flow indicator, or simply order your sight flow indicator at low price and with fast delivery from our online shop.
