Threaded flange for connecting threaded pipes to flanges and flange fittings
Threaded flange according to EN 1092-1 Type 13 with sealing surface B1 made from steel or stainless steel. They are screwed onto pipe elements. As a result, threaded pipe can be connected to flanges or flange fittings. These flange types are available in the nominal widths DN10 - DN400 with a threaded pipe connection of 3/8" to 16" inches. The flange is available in pressure classes PN16 and PN40. The dimensions are stated in the datasheets.
Threaded flange made of stainless steel 1.4571 DN40 flange according DIN PN40 EN1092-1 Typ 13 B1
diameter:
DN40
connection:
PN40
material:
stainless steel
norm:
EN1092-1
Threaded flange made of steel C22.8 / P250GH bare DN50 flange according DIN PN16 EN1092-1 Typ 13 B1
diameter:
DN50
connection:
PN16
material:
steel
norm:
EN1092-1
Threaded flange made of stainless steel 1.4571 DN25 flange according DIN PN40 EN1092-1 Typ 13 B1
diameter:
DN25
connection:
PN40
material:
stainless steel
norm:
EN1092-1
Threaded flange made of steel C22.8 / P250GH bare DN32 flange according DIN PN16/40 EN1092-1 Typ 13 B1
diameter:
DN32
connection:
PN16/40
material:
steel
norm:
EN1092-1
