safety valve 1/2" m Typ SV02 atmospheric discharg for air, made of stainless steel with an FKM seal, pressure 0,2 - 25,0 bar- higher pressures possible in PTFE version
diameter:
1/2" m
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,2 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral gaseous media
cryo-safety-valve DN32 1 1/2" m x 2" fm SV14 for cryogenic liquified gases made of stainless steel seal PTFE pressure 0,2 - 50,0 bar
diameter:
DN32 1 1/2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
without lever
set pressure:
0,2 - 50,0 bar
media:
cryogenic liquified gases
cryo-safety-valve DN25 1" m x 1 1/2" fm SV14 for cryogenic liquified gases made of stainless steel seal PTFE pressure 0,2 - 50,0 bar
diameter:
DN25 1" m x 1 1/2" fm
connection:
male screw threaded BSP-P
lifting:
without lever
set pressure:
0,2 - 50,0 bar
media:
cryogenic liquified gases
safety valve 3/8" m NPT x 3/8" fm SV13 for liquid and gaseous media made of stainless steel seal FKM pressure 0,2 - 25,0 bar without lever
diameter:
3/8" m NPT x 3/8" fm
connection:
male screw threaded NPT
lifting:
without lever
set pressure:
0,2 - 25,0 bar
media:
liquid and gaseous media
safety-valve stainless steel 1/2" x 1" fm with with bellows Typ SV06 with Female screw threaded BSP-P PTFE-seal for liquid media with twist-type lifting mechanism
diameter:
1/2" x 1" fm
connection:
Female screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 70,0 bar
media:
liquid media
cryo-safety-valve DN32 1 1/2" m x 2" fm SV14 for cryogenic liquified gases made of stainless steel with lever seal PTFE pressure 0,2 - 50,0 bar
diameter:
DN32 1 1/2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
with lever
set pressure:
0,2 - 50,0 bar
media:
cryogenic liquified gases
cryo-safety-valve DN20 1" m x 1" fm SV14 for cryogenic liquified gases made of stainless steel with lever seal PTFE pressure 0,2 - 70,0 bar
diameter:
DN20 1" m x 1" fm
connection:
male screw threaded BSP-P
lifting:
with lever
set pressure:
0,2 - 70,0 bar
media:
cryogenic liquified gases
angle-type-safety-valve stainless steel 3/4" x 1 1/4" fm female thread EPDM Typ SV05 for neutral liquid media with twist-type lifting mechanism
diameter:
3/4" x 1 1/4" fm
connection:
Female screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral liquid media
safety-valve stainless steel 1 1/2" x 2" fm female thread EPDM Typ SV05 for neutral liquid media with twist-type lifting mechanism
diameter:
1 1/2" x 2" fm
connection:
Female screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral liquid media
safety valve with with lever und with bellows for liquid media stainless steel 1 1/2" m x 2" fm Typ SV06 with male screw threaded BSP-P FKM-seal
diameter:
1 1/2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
with lever
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
liquid media
safety-valve DN6 1/4" m x 1/2" fm with NPT-thread SV15 for gaseous media made of stainless steel seal MD/ PEEK pressure >500,0 - 1100,0 bar without lifting device angle-type
diameter:
DN6 1/4" m x 1/2" fm
connection:
male screw threaded NPT
lifting:
without lifting device
set pressure:
>500,0 - 1100,0 bar
media:
gaseous media
safety valve 3/4" m x 1 1/4" fm male screw threaded BSP-P SV10 for gaseous media made of stainless steel seal PTFE set pressure 0,5 - 70,0 bar with lever
diameter:
3/4" m x 1 1/4" fm
connection:
male screw threaded BSP-P
lifting:
with lever
set pressure:
0,5 - 70,0 bar
media:
gaseous media
safety-valve DN10 3/8" m x 1" fm SV15 for gaseous media made of stainless steel seal MD / PAI pressure >350,0 bar - 630,0 bar without lifting device angle-type
diameter:
DN10 3/8" m x 1" fm
connection:
male screw threaded BSP-P
lifting:
without lifting device
set pressure:
>350,0 bar - 630,0 bar
media:
gaseous media
angle-type-safety-valve for liquid and gaseous media stainless steel 1 1/2" m x 2" fm male thread NBR Typ SV05 with twist-type lifting mechanism
diameter:
1 1/2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral liquid media
angle-type-safety valve with with bellows for liquid media stainless steel 3/4" m x 1 1/4" fm Typ SV06 with male screw threaded BSP-P FKM-seal and twist-type lifting mechanism
diameter:
3/4" m x 1 1/4" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
liquid media
safety valve with with bellows 2" m x 2" fm stainless steel Typ SV06 with male screw threaded BSP-P NBR-seal for liquid media with with lever
diameter:
2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
with lever
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
liquid media
safety-valve male thread 2" m x 2" fm gunmetal EPDM Typ SV03 for neutral liquid media with twist-type lifting mechanism without bellows
diameter:
2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral liquid media
safety valve 2" male screw threaded BSP-P SV09 for neutral gaseous media made of stainless steel seal FKM set pressure 0,5 - 25,0 bar- higher pressures possible in PTFE version
diameter:
2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral gaseous media
safety-valve for neutral liquid media gunmetal 1" m x 1 1/2" fm male thread NBR Typ SV03 with twist-type lifting mechanism without bellows
diameter:
1" m x 1 1/2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
neutral liquid media
safety-valve DN10 1/4" m x 1" fm with NPT-thread SV15 for gaseous media made of stainless steel seal MD / PAI pressure 50,0 - 180,0 bar without lifting device angle-type
diameter:
DN10 1/4" m x 1" fm
connection:
male screw threaded NPT
lifting:
without lifting device
set pressure:
50,0 - 180,0 bar
media:
gaseous media
safety-valve for liquid media 2" m x 2" fm with with bellows und twist-type lifting mechanism gunmetal Typ SV04 with male screw threaded BSP-P and EPDM-seal
diameter:
2" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
liquid media
safety valve mit einem with bellows 1 1/4" m x 2" fm SV10 for gaseous media made of stainless steel seal NBR set pressure 0,5 - 25,0 bar- higher pressures possible in PTFE version
diameter:
1 1/4" m x 2" fm
connection:
male screw threaded BSP-P
lifting:
twist-type lifting mechanism
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
media:
gaseous media
