2/2 Ways Solenoid valve G 1/4" Inch DN10 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 1/4" Inch
temperature media:
-10°C up to +130°C
flow rate:
1.6 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1" Inch DN25 made of stainless steel 1.4308 seal NBR force pilot operated nominal voltage 24V DC pressure 0.0 - 8 bar
diameter:
DN25
connection:
G 1" Inch
temperature media:
-10°C up to +90°C
flow rate:
10.2 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 2" Inch DN50 made of stainless steel 1.4308 seal NBR force pilot operated nominal voltage 24V DC pressure 0,0 - 6 bar
diameter:
DN50
connection:
G 2" Inch
temperature media:
-10°C up to +90°C
flow rate:
41.2 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/4" Inch DN20 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 10 bar
diameter:
DN20
connection:
G 3/4" Inch
temperature media:
-10°C up to +130°C
flow rate:
6.5 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/4" Inch DN10 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 1/4" Inch
temperature media:
-10°C up to +120°C
flow rate:
1.6 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/8" Inch DN10 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 3/8" Inch
temperature media:
-10°C up to +120°C
flow rate:
2.0 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/4" Inch DN10 made of stainless steel 1.4308 seal NBR force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 1/4" Inch
temperature media:
-10°C up to +80°C
flow rate:
1.6 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/8" Inch DN10 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 3/8" Inch
temperature media:
-10°C up to +130°C
flow rate:
2.0 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/4" Inch DN10 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 1/4" Inch
temperature media:
-10°C up to +130°C
flow rate:
1.6 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1" Inch DN25 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 10 bar
diameter:
DN25
connection:
G 1" Inch
temperature media:
-10°C up to +130°C
flow rate:
10.2 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/4" Inch DN20 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 10 bar
diameter:
DN20
connection:
G 3/4" Inch
temperature media:
-10°C up to +120°C
flow rate:
6.5 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/2" Inch DN10 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 1/2" Inch
temperature media:
-10°C up to +130°C
flow rate:
2.0 m³/h
function:
NC - normally closed
Solenoid valve G 3/8" Inch DN 8.0 made of stainless steel 1.4408 seal EPDM servo controlled nominal voltage 230V 50Hz pressure 0.1 - 16 bar
diameter:
DN 8.0
connection:
G 3/8" Inch
temperature media:
-10°C up to +120°C
flow rate:
1.03 m³/h
function:
NC - normally closed
Solenoid valve G 1/2" Inch DN 8.0 made of stainless steel 1.4408 seal FKM servo controlled nominal voltage 230V 50Hz pressure 0.1 - 16 bar
diameter:
DN 8.0
connection:
G 1/2" Inch
temperature media:
-10°C up to +120°C
flow rate:
1.03 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 2" Inch DN50 made of stainless steel 1.4408 seal EPDM servo controlled nominal voltage 24V DC pressure 0.5 - 16 bar
diameter:
DN50
connection:
G 2" Inch
temperature media:
-10°C up to +130°C
flow rate:
41.2 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/8" Inch DN10 made of stainless steel 1.4308 seal NBR force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 3/8" Inch
temperature media:
-10°C up to +80°C
flow rate:
2.0 m³/h
function:
NC - normally closed
Solenoid valve G 3/8" Inch DN 8.0 made of stainless steel 1.4408 seal FKM servo controlled nominal voltage 24V DC pressure 0.1 - 10 bar
diameter:
DN 8.0
connection:
G 3/8" Inch
temperature media:
-10°C up to +120°C
flow rate:
1.03 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/2" Inch DN10 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 1/2" Inch
temperature media:
-10°C up to +120°C
flow rate:
2.0 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/2" Inch DN13.0 made of stainless steel 1.4408 seal NBR servo controlled nominal voltage 24V DC pressure 0.5 - 16 bar
diameter:
DN13.0
connection:
G 1/2" Inch
temperature media:
-10°C up to +80°C
flow rate:
3.8 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/8" Inch DN10 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 3/8" Inch
temperature media:
-10°C up to +120°C
flow rate:
2.0 m³/h
function:
NC - normally closed
Solenoid valve G 1/4" Inch DN 8.0 made of stainless steel 1.4408 seal FKM servo controlled nominal voltage 230V 50Hz pressure 0.1 - 16 bar
diameter:
DN 8.0
connection:
G 1/4" Inch
temperature media:
-10°C up to +120°C
flow rate:
1.03 m³/h
function:
NC - normally closed
Solenoid valve G 1/4" Inch DN 8.0 made of stainless steel 1.4408 seal NBR servo controlled nominal voltage 230V 50Hz pressure 0.1 - 16 bar
diameter:
DN 8.0
connection:
G 1/4" Inch
temperature media:
-10°C up to +80°C
flow rate:
1.03 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 3/8" Inch DN10 made of stainless steel 1.4308 seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar
diameter:
DN10
connection:
G 3/8" Inch
temperature media:
-10°C up to +130°C
flow rate:
2.0 m³/h
function:
NC - normally closed
2/2 Ways Solenoid valve G 1/2" Inch DN10 made of stainless steel 1.4308 seal FKM force pilot operated nominal voltage 24V DC pressure 0.0 - 16 bar
diameter:
DN10
connection:
G 1/2" Inch
temperature media:
-10°C up to +120°C
flow rate:
2.0 m³/h
function:
NC - normally closed
