AV03010015

Globe valve DN 250 AV03 cast steel 1.0619+N Isolation plug

€12,100.80*

€14,399.95 VAT included.

Delivery time: 1 - 2 weeks

Delivery information

Equipment

VS01010415

joint set flange/flange DN250 - 10" Inch for flange PN40 steel

€240.00*

€285.60 VAT included.


×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

Certified

Certified

Product number: AV03010015
Globe valve DN 250 AV03 cast steel 1.0619+N Isolation plug

Globe valve DN 250 in straight through with bellow material cast steel 1.0619+N authorization TA-Luft Isolation plug

product: Globe valve
type: AV03
manufacturer: NieRuf
diameter: DN 250
flange: flange acc. DIN EN 1092
pressure: PN40
seal: metal
media: liquid and gaseous media
temperature: to max +450°C - depending on working pressure
pressure range: max. 40 bar depending on operating temperature
design: straight through with bellow
body material: cast steel 1.0619+N
material spindel unit: cast steel 1.0619+N
handwheel: cast iron with epoxy-coating (non-rising)
plug: Isolation plug
bellow: stainless steel 1.4571
length: acc DIN EN 558 series 1
approval: EN ISO 15848-1 / TA Luft TÜV-Prüf-Nr: TA 07 2016 C04
installation position: any position, spindle preferably vertical
product feature: Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN. At high differential pressures a balancing plug is necessary!

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

Globe valve DN 250 AV03 cast steel 1.0619+N Isolation plug

Article no. : AV03010015
product: Globe valve
type: AV03
manufacturer: NieRuf
diameter: DN 250
flange: flange acc. DIN EN 1092
pressure: PN40
seal: metal
media: liquid and gaseous media
temperature: to max +450°C - depending on working pressure
pressure range: max. 40 bar depending on operating temperature
design: straight through with bellow
body material: cast steel 1.0619+N
material spindel unit: cast steel 1.0619+N
handwheel: cast iron with epoxy-coating (non-rising)
plug: Isolation plug
bellow: stainless steel 1.4571
length: acc DIN EN 558 series 1
approval: EN ISO 15848-1 / TA Luft TÜV-Prüf-Nr: TA 07 2016 C04
installation position: any position, spindle preferably vertical
product feature: Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN. At high differential pressures a balancing plug is necessary!
