only for B2B-Customers

short delivery time

purchase on invoice

Technical advice +497143/96669-00

Steam-flange ball valve DN150 FK05 stainless steel 1.4408

FK05010013
quantity (pcs.):
2,636.80€ * 3,058.69€ incl. VAT
*Price plus VAT and shipping costs

Delivery time: 3-5 working days

datasheet 3D model
All the information quoted in these resistance tables is based on industrial experience and the data of our material and compound manufacturers. NieRuf GmbH makes no guarantee, however, as to the correctness and completeness of this informations.

If materials are rated as ''limited suitability'', the time of impact has to be considered. At a long period of impact these materials can be heavily attacked or even destroyed. There- fore these parts are rated as wear parts and are not included in the standard warranty conditions.
Questions about the article?
Our colleague Meiko Holzinger will be happy to help:
Tel: +497143/9666-904
E-Mail: holzinger@nieruf.de
technical details
Steam-flange ball valve DN150 FK05 stainless steel 1.4408
Steam-flange ball valve DN150 PN16 FK05 body stainless steel 1.4408 ball stainless steel 1.4408 seal PTFE / TFM for gaseous for example steam
diameter: DN150
connection: flange dimensions acc. to EN 1092-1
Seal steam: PTFE + TFM + Graphite
media: gaseous for example steam
temperature: -20°C up to +180°C - depending on working pressure and media
max. pressure: PN16
design: full port design
body material: stainless steel 1.4408
ball material: stainless steel 1.4408
ball seal: PTFE / TFM
length: DIN EN 558 R 27
actuator: lever handle made of stainless steel
installation position: any position
product description: This high quality ball valve is made of stainless steel with blow out proof stem design. Two-piece body valve with mounting flange acc. to DIN ISO 5211. Stem extension is made of stainless steel. The stem seal is 3 - side covered.
Steam-flange ball valve DN150 FK05 stainless steel 1.4408

Quickly and easily transfer the specification of our valves into your tender text or specification.
Just copy the text box below and paste it into your tender.

Steam-flange ball valve DN150 FK05 stainless steel 1.4408
