FK01020012

Flange ball valve DN125 FK01 GGG40 ball steel chrome plated DVGW-Gas

€689.90*

€820.98 VAT included.

Delivery time: 3 - 5 working days

Delivery information

Equipment

VS01010112

joint set flange/flange DN125 - 5" Inch for flange PN10/16/25 steel

€16.00*

€19.04 VAT included.


FD01000112

flange seal DN125 PN10/16 141x192x2 Klingersil C 4400

€6.10*

€7.26 VAT included.


FL01020112

Flange DN125 PN10/16 EN1092-1 11 B1 C22.8 / P250GH bare

€52.60*

€62.59 VAT included.


×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

Certified

Certified

Product number: FK01020012
Flange ball valve DN125 FK01 GGG40 ball steel chrome plated DVGW-Gas

Flange ball valve DN125 FK01 body spheroidal graphite cast iron GJS 400-18 ball steel chrome plated seal PTFE approval DVGW gas

product: Flange ball valve
type: FK01
manufacturer: NieRuf
diameter: DN125
connection: flange dimensions acc. DIN EN 1092-2 PN 16
Seal steam: O-rings FKM
ball seal: PTFE
media: gas: 1., 2. and 3. gas category
temperature: -20°C up to +60°C - depending on working pressure and media
max. pressure: PN16
design: full port design with chrome plated steel ball
body material: spheroidal graphite cast iron 5.3103
ball material: steel chrome plated 1.0503
length: DIN EN 558-1 R14
actuator: hand lever made of alu with yellow cover
installation position: any position
authorized for: DVGW-Gas
product description: This high quality ball valve is made of spheroidal graphite cast iron with Fire-Safe-Design and floating chrome plated steel ball. Two-piece body valve with flange dimensions acc. DIN EN 1092-2 PN 16 dimensions acc. to DIN EN 1092-2 PN 16.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

Flange ball valve DN125 FK01 GGG40 ball steel chrome plated DVGW-Gas

Article no. : FK01020012
product: Flange ball valve
type: FK01
manufacturer: NieRuf
diameter: DN125
connection: flange dimensions acc. DIN EN 1092-2 PN 16
Seal steam: O-rings FKM
ball seal: PTFE
media: gas: 1., 2. and 3. gas category
temperature: -20°C up to +60°C - depending on working pressure and media
max. pressure: PN16
design: full port design with chrome plated steel ball
body material: spheroidal graphite cast iron 5.3103
ball material: steel chrome plated 1.0503
length: DIN EN 558-1 R14
actuator: hand lever made of alu with yellow cover
installation position: any position
authorized for: DVGW-Gas
product description: This high quality ball valve is made of spheroidal graphite cast iron with Fire-Safe-Design and floating chrome plated steel ball. Two-piece body valve with flange dimensions acc. DIN EN 1092-2 PN 16 dimensions acc. to DIN EN 1092-2 PN 16.
