angle-type overflow valve 1" inch male type UV15 stainless steel 50,0 - 70,0 bar seal PTFE for liquid and gaseous media counter pressure compensated up to 20 bar
angle-type overflow valve 3/4" inch male type UV15 stainless steel 2,8 - 5,3 bar seal PTFE for liquid and gaseous media counter pressure compensated up to 4 bar
piston overflow valve DN 32 type UV13 made of stainless steel AISI 316L pressure range 2,0 - 5,0 bar seal metall for water
Millibar overflow valve DN50 flange type UV17 stainless steel 50 - 500 mbar seal FKM / PTFE for neutral gaseous media
straightway form overflow valve 1/2" inch female type UV07 made of stainless steel CF8M / 316L pressure range 1,5 - 6,0 bar seal EPDM for liquid and gaseous media
piston overflow valve DN 15 type UV13 made of stainless steel AISI 316L pressure range 1,0 - 3,0 bar seal metall for steam
angle-type overflow valve 3/4" inch fm type UV15 stainless steel 0,5 - 1,0 bar seal PTFE for liquid and gaseous media counter pressure compensated up to 4 bar
Millibar overflow valve DN20 flange ANSI 150 type UV18 stainless steel 7 - 100 mbar seal EPDM / PTFE for neutral gaseous media
NieRuf offers a wide range of stainless-steel overflow-valves. They are being manufactured as straight form or angle form, depending on the requirements. The valve in straight form should always be mounted between two shut-off valves. This allows you to take it out easily and efficiently for cleaning or repairing purposes. For stainless-steel valves, different alloys can be used. Please find the material references for stainless steel in our data sheets.
All stainless steel overflow valves can be manufactured with either flange connection or internal or external thread depending on the requirements. Stainless-steel overflow-valves with flange connection are available in the nominal sizes DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80 and DN100. The stainless-steel overflow-valves with thread connection are available in 3/8“, ½“, ¾“, 1“, 1 ¼“, 1 ½“ and 2“ Inch. Please contact us if you need special sizes. The range of adjustment can be set between 0,5 and 20 bar, the seal can be FKM, EPDM, PTFE or metal. If you let us know which setting you need, we can set the valve for you during manufacturing.
Special requests, spare parts or a quick support? Our staff will answer your questions and concerns immediately.
Mon. - Fri. from 08:30 - 17:00
Phone: +49 7143/9666-901
sales@nieruf.com
Commitment engenders trust. We stand by our word and are convinced that as a result not only our customers but also everyone we work with can rely on us.
We always strive to find the best solution for our customers. It is our goal and incentive to have completely satisfied customers.
Technical and commercial expertise form the basis for developing qualified solutions tailored precisely to the needs of our customers.
We do not adhere to rigid guidelines but instead focus on the individual wishes and needs of our customers. They are more important to us than internal company processes.
