DM11000004

Piston-pressure reducing valve DN20 DM11 stainless steel FPM / FKM 2.0 - 20.0 bar

€955.70*

€1,137.28 VAT included.

Delivery time: 3 - 5 working days

Delivery information

Equipment

VS01000104

joint set flange/flange DN20 - 3/4" Inch for flange PN10/16/25/40 stainless steel

€4.00*

€4.76 VAT included.


MM05101001

pressure gauge 0 - 40,0 bar G 1/4" axial 50 mm stainless steel MM05

€78.10*

€92.94 VAT included.


FL01000104

Welding neck flange DN20 PN10/16/25/40 EN1092-1 11 B1 1.4541

€22.50*

€26.78 VAT included.


FD01000104

flange seal DN20 PN10/16/25/40 27x61x2 Klingersil C 4400

€1.70*

€2.02 VAT included.


×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

24 months warranty

24 months warranty

Certified

Certified

Product number: DM11000004
Piston-pressure reducing valve DN20 DM11 stainless steel FPM / FKM 2.0 - 20.0 bar

Piston-pressure reducing valve DN20 flange made of stainless steel seal FPM / FKM for liquid and neutral gaseous media, set pressure 2.0 - 20.0 bar

product: Piston-pressure reducing valve
type: DM11
manufacturer: NieRuf
diameter: DN20
connection: flange
material: stainless steel
seal: FPM / FKM
media: liquid and neutral gaseous media
temperature: -10°C up to +190°C
range of adjustment: 2.0 - 20.0 bar
max. inlet pressure: 40 bar
design: straightway form
installation position: any position
product feature: This high quality pressure reducing valve is made in Germany. A pressure reducing valve with stainless steel, cast iron flanges, dirt-trap and double-ended G 1/4" manometer fitting

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

Piston-pressure reducing valve DN20 DM11 stainless steel FPM / FKM 2.0 - 20.0 bar

Article no. : DM11000004
product: Piston-pressure reducing valve
type: DM11
manufacturer: NieRuf
diameter: DN20
connection: flange
material: stainless steel
seal: FPM / FKM
media: liquid and neutral gaseous media
temperature: -10°C up to +190°C
range of adjustment: 2.0 - 20.0 bar
max. inlet pressure: 40 bar
design: straightway form
installation position: any position
product feature: This high quality pressure reducing valve is made in Germany. A pressure reducing valve with stainless steel, cast iron flanges, dirt-trap and double-ended G 1/4" manometer fitting

No spare parts were found for the item number .
