DM20000004
pressure reducing valve DN 20 DM20 stainless steel EPDM 1.5 - 6.0 bar
- Lead time
- 3 - 5 working days
Equipment
pressure gauge 0 - 10,0 bar G 1/4" axial 50 mm stainless steel MM05
€103.89 VAT included.
Welding neck flange DN20 PN10/16/25/40 EN1092-1 11 B1 1.4541
€18.92 VAT included.
joint set flange/flange DN20 - 3/4" Inch for flange PN10/16/25/40 stainless steel
€4.28 VAT included.
flange seal DN20 PN10/16/25/40 27x61x2 Klingersil C 4400
€2.14 VAT included.
Questions about the article?
Our employee Richie Rost
will be happy to help you
pressure reducing valve DN 20 DM20 stainless steel EPDM 1.5 - 6.0 bar
pressure reducing valve DN 20 flange DIN EN 1092 made of stainless steel seal EPDM FDA for liquid and neutral gaseous media, pressure 1.5 - 6.0 bar
| product | pressure reducing valve |
|---|---|
| type | DM20 |
| manufacturer | NieRuf |
| diameter | DN 20 |
| connection | flange DIN EN 1092 |
| material | stainless steel |
| seal | EPDM |
| media | liquid and neutral gaseous media |
| temperature | -20°C up to +120°C |
| range of adjustment | 1.5 - 6.0 bar |
| max. inlet pressure | 40 bar |
| design | straightway form |
| installation position | any position |
| product feature | This version with cast iron flanges meets the requirements of EU regulation EG1935/2004 and is therefore suitable for use in the food sector. The EPDM seals are FDA-compliant. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
pressure reducing valve DN 20 DM20 stainless steel EPDM 1.5 - 6.0 bar
Article no.
: DM20000004
product:
pressure reducing valve
type:
DM20
manufacturer:
NieRuf
diameter:
DN 20
connection:
flange DIN EN 1092
material:
stainless steel
seal:
EPDM
media:
liquid and neutral gaseous media
temperature:
-20°C up to +120°C
range of adjustment:
1.5 - 6.0 bar
max. inlet pressure:
40 bar
design:
straightway form
installation position:
any position
product feature:
This version with cast iron flanges meets the requirements of EU regulation EG1935/2004 and is therefore suitable for use in the food sector. The EPDM seals are FDA-compliant.
Equipment
flange seal DN20 PN10/16/25/40 27x61x2 Klingersil C 4400
Lead time: in stock
Welding neck flange DN20 PN10/16/25/40 EN1092-1 11 B1 1.4541
Lead time: in stock
Compact ball valve DN20 PN40 FK04 stainless steel 1.4408
Lead time: in stock
pressure gauge 0 - 10,0 bar G 1/4" axial 50 mm stainless steel MM05
Lead time: in stock
joint set flange/flange DN20 - 3/4" Inch for flange PN10/16/25/40 stainless steel
Lead time: in stock
