UV11010006
flange overflow valve DN 32 PN40 UV11 stainless steel CF8M / 316L 0,5 - 2,0 bar
- Lead time
- 3 - 5 working days
Equipment
pressure gauge 0 - 4,0 bar G 1/4" axial 50 mm stainless steel MM05
€103.89 VAT included.
joint set flange/flange DN32 - 1 1/4" Inch for flange PN10/16/25/40 stainless steel
€8.09 VAT included.
Welding neck flange DN32 PN10/16/25/40 EN1092-1 11 B1 1.4541
€33.44 VAT included.
flange seal DN32 PN10/16/25/40 43x82x2 Klingersil C 4400
€5.24 VAT included.
Questions about the article?
Our employee Richie Rost
will be happy to help you
flange overflow valve DN 32 PN40 UV11 stainless steel CF8M / 316L 0,5 - 2,0 bar
flange overflow valve DN 32 PN40 type UV11 made of stainless steel CF8M / 316L pressure range 0,5 - 2,0 bar seal EPDM for liquid and gaseous media
| product | flange overflow valve |
|---|---|
| type | UV11 |
| manufacturer | NieRuf |
| diameter | DN 32 PN40 |
| connection | flange acc. DIN EN 1092 |
| seal | EPDM |
| media | liquid and gaseous media |
| temperature | -20°C to +120°C |
| range of adjustment | 0,5 - 2,0 bar |
| design | straightway form |
| material | stainless steel CF8M / 316L |
| installation position | any position |
| SIL - safety integrity level | SIL 2 |
| product feature | High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
flange overflow valve DN 32 PN40 UV11 stainless steel CF8M / 316L 0,5 - 2,0 bar
Article no.
: UV11010006
product:
flange overflow valve
type:
UV11
manufacturer:
NieRuf
diameter:
DN 32 PN40
connection:
flange acc. DIN EN 1092
seal:
EPDM
media:
liquid and gaseous media
temperature:
-20°C to +120°C
range of adjustment:
0,5 - 2,0 bar
design:
straightway form
material:
stainless steel CF8M / 316L
installation position:
any position
SIL - safety integrity level:
SIL 2
product feature:
High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
Equipment
flange seal DN32 PN10/16/25/40 43x82x2 Klingersil C 4400
Lead time: in stock
Welding neck flange DN32 PN10/16/25/40 EN1092-1 11 B1 1.4541
Lead time: in stock
pressure gauge 0 - 4,0 bar G 1/4" axial 50 mm stainless steel MM05
Lead time: in stock
joint set flange/flange DN32 - 1 1/4" Inch for flange PN10/16/25/40 stainless steel
Lead time: in stock
pipe bend (welded) 90° 42,4 x 2,0 stainless steel 1.4571
Lead time: in stock
reducing bush (welded) 42,4 x 2,0 to 33,7 x 2,0 stainless steel 1.4571
Lead time: 3 - 5 working days
