ZR10000112
swing check valve with spring DN125 ZR10 Alu bronze 2.0975 / C958 EPDM
- Lead time
- 3 - 5 working days
Questions about the article?
Our employee Richie Rost
will be happy to help you
swing check valve with spring DN125 ZR10 Alu bronze 2.0975 / C958 EPDM
swing check valve with spring DN125 PN 10/16 DIN EN 1092-1 Form B Alu bronze 2.0975 / C958 seal EPDM for liquid and gaseous media
| product | swing check valve with spring |
|---|---|
| type | ZR10 |
| manufacturer | NieRuf |
| design | swing check valve |
| diameter | DN125 |
| body material | Alu bronze 2.0975 / C958 |
| disc material | Duplex 1.4469 / A 890 Grade 5A |
| seal | EPDM |
| temperature | -10°C up to +150°C |
| connection | flange |
| flange | PN 10/16 DIN EN 1092-1 Form B |
| pressure range | 0 - 30 bar |
| media | liquid and gaseous media |
| tightness acc. to DIN EN 12266 | leak rate A |
| option | with spring made of Hastelloy C4 |
| installation position | direction of flow horizontal (disc must be free-hanging), vertical from below |
| product feature | short face to face |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
swing check valve with spring DN125 ZR10 Alu bronze 2.0975 / C958 EPDM
Article no.
: ZR10000112
product:
swing check valve with spring
type:
ZR10
manufacturer:
NieRuf
design:
swing check valve
diameter:
DN125
body material:
Alu bronze 2.0975 / C958
disc material:
Duplex 1.4469 / A 890 Grade 5A
seal:
EPDM
temperature:
-10°C up to +150°C
connection:
flange
flange:
PN 10/16 DIN EN 1092-1 Form B
pressure range:
0 - 30 bar
media:
liquid and gaseous media
tightness acc. to DIN EN 12266:
leak rate A
option:
with spring made of Hastelloy C4
installation position:
direction of flow horizontal (disc must be free-hanging), vertical from below
product feature:
short face to face
