DM12000106
membrane pressure reducing valve 1 1/4" Inch NPT DM12 stainless steel FPM / FKM 1.5 - 6.0 bar
Delivery time: 3 - 5 working days
Equipment
pressure gauge 0 - 10,0 bar G 1/4" axial 50 mm stainless steel MM05
€101.27 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
membrane pressure reducing valve 1 1/4" Inch NPT female thread NPT made of stainless steel seal FPM / FKM for liquid and neutral gaseous media, set pressure 1.5 - 6.0 bar
product: | membrane pressure reducing valve |
---|---|
type: | DM12 |
manufacturer: | NieRuf |
diameter: | 1 1/4" Inch NPT |
connection: | female thread NPT |
material: | stainless steel |
seal: | FPM / FKM |
media: | liquid and neutral gaseous media |
temperature: | -10°C up to +190°C |
range of adjustment: | 1.5 - 6.0 bar |
max. inlet pressure: | 40 bar |
design: | straightway form |
installation position: | any position |
product feature: | This high quality pressure reducing valve is made in Germany. A pressure reducing valve with stainless steel dirt-trap and double-ended G 1/4" manometer fitting |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
membrane pressure reducing valve 1 1/4" Inch NPT DM12 stainless steel FPM / FKM 1.5 - 6.0 bar
Article no.
: DM12000106
product:
membrane pressure reducing valve
type:
DM12
manufacturer:
NieRuf
diameter:
1 1/4" Inch NPT
connection:
female thread NPT
material:
stainless steel
seal:
FPM / FKM
media:
liquid and neutral gaseous media
temperature:
-10°C up to +190°C
range of adjustment:
1.5 - 6.0 bar
max. inlet pressure:
40 bar
design:
straightway form
installation position:
any position
product feature:
This high quality pressure reducing valve is made in Germany. A pressure reducing valve with stainless steel dirt-trap and double-ended G 1/4" manometer fitting
