UV10020007

flange overflow valve DN 40 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

€1,231.70*

€1,465.72 VAT included.

*Prices excl. VAT plus shipping costs

Lead time: 3 - 5 working days

Equipment

VS01010107

joint set flange/flange DN40 - 1 1/2" Inch for flange PN10/16/25/40 steel

€6.40*

€7.62 VAT included.

MM03000301

pressure gauge G 1/4" axial 50 mm steel MM03 0 - 10,0 bar

€10.60*

€12.61 VAT included.

FD01000107

flange seal DN40 PN10/16/25/40 49x92x2 Klingersil C 4400

€2.70*

€3.21 VAT included.

FL01020107

Flange DN40 PN10/16/25/40 EN1092-1 11 B1 C22.8 / P250GH bare

€18.50*

€22.02 VAT included.

Resistance check

Our employee <strong>Richie Rost</strong><br>will be happy to help you

Questions about the article?

Our employee Richie Rost
will be happy to help you

Tel: +49714396669-18

E-Mail: rost@nieruf.com

NIERUF-SERVICE

24 months warranty

Certified

Downloads

3D model

Datasheet

flange overflow valve DN 40 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

flange overflow valve DN 40 PN40 type UV10 made of gunmetal/brass pressure range 1,5 - 6,0 bar seal FKM for liquid and gaseous media

product	flange overflow valve
type	UV10
manufacturer	NieRuf
diameter	DN 40 PN40
connection	flange acc. DIN EN 1092
seal	FKM
media	liquid and gaseous media
temperature	-10°C to +120°C
range of adjustment	1,5 - 6,0 bar
design	straightway form
material	gunmetal/brass
installation position	any position
SIL - safety integrity level	SIL 2
product feature	High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

flange overflow valve DN 40 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

Article no. : UV10020007
product: flange overflow valve
type: UV10
manufacturer: NieRuf
diameter: DN 40 PN40
connection: flange acc. DIN EN 1092
seal: FKM
media: liquid and gaseous media
temperature: -10°C to +120°C
range of adjustment: 1,5 - 6,0 bar
design: straightway form
material: gunmetal/brass
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
