UV10020004

flange overflow valve DN 20 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

€804.40*

€957.24 VAT included.

Delivery time: 3 - 5 working days

Delivery information

Equipment

FL01020104

Flange DN20 PN10/16/25/40 EN1092-1 11 B1 C22.8 / P250GH bare

€12.10*

€14.40 VAT included.


FD01000104

flange seal DN20 PN10/16/25/40 27x61x2 Klingersil C 4400

€1.70*

€2.02 VAT included.


MM03000301

pressure gauge G 1/4" axial 50 mm steel MM03 0 - 10,0 bar

€10.60*

€12.61 VAT included.


VS01010104

joint set flange/flange DN20 - 3/4" Inch for flange PN10/16/25/40 steel

€3.60*

€4.28 VAT included.


×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

24 months warranty

24 months warranty

Certified

Certified

Product number: UV10020004
flange overflow valve DN 20 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

flange overflow valve DN 20 PN40 type UV10 made of gunmetal/brass pressure range 1,5 - 6,0 bar seal FKM for liquid and gaseous media

product: flange overflow valve
type: UV10
manufacturer: NieRuf
diameter: DN 20 PN40
connection: flange acc. DIN EN 1092
seal: FKM
media: liquid and gaseous media
temperature: -10°C to +95°C
range of adjustment: 1,5 - 6,0 bar
design: straightway form
material: gunmetal/brass
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

flange overflow valve DN 20 PN40 UV10 gunmetal/brass 1,5 - 6,0 bar

Article no. : UV10020004
product: flange overflow valve
type: UV10
manufacturer: NieRuf
diameter: DN 20 PN40
connection: flange acc. DIN EN 1092
seal: FKM
media: liquid and gaseous media
temperature: -10°C to +95°C
range of adjustment: 1,5 - 6,0 bar
design: straightway form
material: gunmetal/brass
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
