FK07000007
3/2 cross over ball valve DN40 FK07 C22 steel zinc plated 1.040 Kugel stainless steel 1.4404
- Lead time
- 3 - 5 working days
Questions about the article?
Our employee Richie Rost
will be happy to help you
3/2 cross over ball valve DN40 FK07 C22 steel zinc plated 1.040 Kugel stainless steel 1.4404
3/2 cross over ball valve DN40 PN16/40 FK07 body C22 steel zinc plated 1.040 ball stainless steel 1.4404 seal TFM 25% GF for liquid and gaseous media
| product | 3/2 cross over ball valve |
|---|---|
| type | FK07 |
| manufacturer | NieRuf |
| diameter | DN40 |
| connection | flange |
| Seal steam | O-ring Viton |
| ball seal | TFM 25% GF |
| media | liquid and gaseous media |
| temperature | -20°C up to +180°C - depending on working pressure and media |
| max. pressure | PN16/40 |
| design | reduced port design |
| body material | C22 steel zinc plated 1.040 |
| ball material | stainless steel 1.4404 / AISI 316L |
| length | 71mm |
| actuator | hand lever with blue plastic cover |
| installation position | any position |
| product description | This high quality 3/2 valve with compactdesign and the body is steel zinc plated. This 3/2 cross over ball valve with sealing on the output side and direction of flow see graphical symbol |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
3/2 cross over ball valve DN40 FK07 C22 steel zinc plated 1.040 Kugel stainless steel 1.4404
Article no.
: FK07000007
product:
3/2 cross over ball valve
type:
FK07
manufacturer:
NieRuf
diameter:
DN40
connection:
flange
Seal steam:
O-ring Viton
ball seal:
TFM 25% GF
media:
liquid and gaseous media
temperature:
-20°C up to +180°C - depending on working pressure and media
max. pressure:
PN16/40
design:
reduced port design
body material:
C22 steel zinc plated 1.040
ball material:
stainless steel 1.4404 / AISI 316L
length:
71mm
actuator:
hand lever with blue plastic cover
installation position:
any position
product description:
This high quality 3/2 valve with compactdesign and the body is steel zinc plated. This 3/2 cross over ball valve with sealing on the output side and direction of flow see graphical symbol
Equipment
flange seal DN40 PN10/16/25/40 49x92x2 Klingersil C 4400
Lead time: in stock
Flange DN40 PN10/16/25/40 EN1092-1 11 B1 C22.8 / P250GH bare
Lead time: in stock
joint set flange/flange DN40 - 1 1/2" Inch for flange PN10/16/25/40 steel
Lead time: in stock
