CV01000105
Coaxial-valve 1" inch fm - DN25 brass 230V AC NO
Delivery time: On request
Equipment
Questions about the article?
Our employee Daniel Beck
will be happy to help you
2/2 Way-valve Coaxial-valve 1" inch fm - DN25 made of brass, direct acting up to max. 40 bar, NO - normal open voltage 230V AC
| product: | Coaxial-valve |
|---|---|
| type: | CV01 |
| manufacturer: | NieRuf |
| design: | 2/2 Way-valve |
| diameter: | 1" inch fm - DN25 |
| connection: | female thread |
| material: | brass |
| seal: | FPM |
| function: | NO - normally open |
| operation: | with spring return |
| control: | direct acting |
| voltage: | 230V AC |
| media: | liquid and gaseous media |
| temperature: | from -20°C to max. +100°C |
| pressure range: | up to max. 40 bar |
| installation position: | any position |
| product feature: | Maintenance-free, backpressure-leakproof, bi-directional flow direction with short switching time. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Coaxial-valve 1" inch fm - DN25 brass 230V AC NO
Article no.
: CV01000105
product:
Coaxial-valve
type:
CV01
manufacturer:
NieRuf
design:
2/2 Way-valve
diameter:
1" inch fm - DN25
connection:
female thread
material:
brass
seal:
FPM
function:
NO - normally open
operation:
with spring return
control:
direct acting
voltage:
230V AC
media:
liquid and gaseous media
temperature:
from -20°C to max. +100°C
pressure range:
up to max. 40 bar
installation position:
any position
product feature:
Maintenance-free, backpressure-leakproof, bi-directional flow direction with short switching time.
