RV02100515
check valve DN 250 cast steel 1.0619 metall PN 10 to 16 (+ASME B16.5 / ANSI 150)
- Lead time
- 3 - 5 working days
Questions about the article?
Our employee Richie Rost
will be happy to help you
check valve DN 250 cast steel 1.0619 metall PN 10 to 16 (+ASME B16.5 / ANSI 150)
disco check valve DN 250 made of cast steel 1.0619 seal metall for liquid and gaseous media PN 10 to 16 (+ASME B16.5 / ANSI 150)
| product | check valve |
|---|---|
| type | RV02 |
| manufacturer | NieRuf |
| design | disco check valve |
| diameter | DN 250 |
| body material | cast steel 1.0619 |
| disc material | stainless steel 1.4408 / CF8M |
| seal | metall |
| tightness acc. to DIN EN 12266 | leak rate ≥ G |
| temperature | -10°C up to +300°C |
| flange | PN 10 to 16 (+ASME B16.5 / ANSI 150) |
| pressure range | 0 - 50 bar |
| Kv-value in m3/h | 643,00 |
| spring material | stainless steel 1.4571 / AISI 316Ti |
| media | liquid and gaseous media |
| installation position | any position |
| product feature | face to face according to factory f-t-f dimension |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
check valve DN 250 cast steel 1.0619 metall PN 10 to 16 (+ASME B16.5 / ANSI 150)
Article no.
: RV02100515
product:
check valve
type:
RV02
manufacturer:
NieRuf
design:
disco check valve
diameter:
DN 250
body material:
cast steel 1.0619
disc material:
stainless steel 1.4408 / CF8M
seal:
metall
tightness acc. to DIN EN 12266:
leak rate ≥ G
temperature:
-10°C up to +300°C
flange:
PN 10 to 16 (+ASME B16.5 / ANSI 150)
pressure range:
0 - 50 bar
Kv-value in m3/h:
643,00
spring material:
stainless steel 1.4571 / AISI 316Ti
media:
liquid and gaseous media
installation position:
any position
product feature:
face to face according to factory f-t-f dimension
