UV07020103
straightway form overflow valve 1/2" inch female UV07 stainless steel CF8M / 316L 1,5 - 6,0 bar
- Lead time
- 3 - 5 working days
Equipment
hexagon nipple 1/2" inch male stainless steel 316
€2.26 VAT included.
pressure gauge 0 - 10,0 bar G 1/4" axial 50 mm stainless steel MM05
€103.89 VAT included.
Questions about the article?
Our employee Richie Rost
will be happy to help you
straightway form overflow valve 1/2" inch female UV07 stainless steel CF8M / 316L 1,5 - 6,0 bar
straightway form overflow valve 1/2" inch female type UV07 made of stainless steel CF8M / 316L pressure range 1,5 - 6,0 bar seal EPDM for liquid and gaseous media
| product | straightway form overflow valve |
|---|---|
| type | UV07 |
| manufacturer | NieRuf |
| diameter | 1/2" inch female |
| connection | female thread BSP-P |
| seal | EPDM |
| media | liquid and gaseous media |
| temperature | -20°C to +120°C |
| range of adjustment | 1,5 - 6,0 bar |
| design | straightway form |
| material | stainless steel CF8M / 316L |
| installation position | any position |
| SIL - safety integrity level | SIL 2 |
| product feature | High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
straightway form overflow valve 1/2" inch female UV07 stainless steel CF8M / 316L 1,5 - 6,0 bar
Article no.
: UV07020103
product:
straightway form overflow valve
type:
UV07
manufacturer:
NieRuf
diameter:
1/2" inch female
connection:
female thread BSP-P
seal:
EPDM
media:
liquid and gaseous media
temperature:
-20°C to +120°C
range of adjustment:
1,5 - 6,0 bar
design:
straightway form
material:
stainless steel CF8M / 316L
installation position:
any position
SIL - safety integrity level:
SIL 2
product feature:
High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
