UV12020010

flange overflow valve DN 80 PN40 UV12 stainless steel AISI 316L 1,0 - 6,0 bar

€4,801.60*

€5,713.90 VAT included.

Delivery time: 3 - 5 working days

Delivery information

Equipment

MM05000701

pressure gauge G 1/4" radial 50 mm stainless steel MM05 0 - 10,0 bar

€69.20*

€82.35 VAT included.


FL01000210

Welding neck flange DN80 PN25/40 EN1092-1 11 B1 1.4541

€81.90*

€97.46 VAT included.


FD01000110

flange seal DN80 PN10/16/25/40 89x142x2 Klingersil C 4400

€4.20*

€5.00 VAT included.


VS01000410

joint set flange/flange DN80 - 3" Inch for flange PN40 stainless steel

€17.60*

€20.94 VAT included.


×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

24 months warranty

24 months warranty

Certified

Certified

Product number: UV12020010
flange overflow valve DN 80 PN40 UV12 stainless steel AISI 316L 1,0 - 6,0 bar

flange overflow valve DN 80 PN40 type UV12 made of stainless steel AISI 316L pressure range 1,0 - 6,0 bar seal FKM for liquid and gaseous media

product: flange overflow valve
type: UV12
manufacturer: NieRuf
diameter: DN 80 PN40
connection: flange acc. DIN EN 1092
seal: FKM
media: liquid and gaseous media
temperature: -10°C to +95°C
range of adjustment: 1,0 - 6,0 bar
design: straightway form
material: stainless steel AISI 316L
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

flange overflow valve DN 80 PN40 UV12 stainless steel AISI 316L 1,0 - 6,0 bar

Article no. : UV12020010
product: flange overflow valve
type: UV12
manufacturer: NieRuf
diameter: DN 80 PN40
connection: flange acc. DIN EN 1092
seal: FKM
media: liquid and gaseous media
temperature: -10°C to +95°C
range of adjustment: 1,0 - 6,0 bar
design: straightway form
material: stainless steel AISI 316L
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
