swing check valve DN300 ZR02 ANSI 150 stainless steel CF8M FKM

ZR02100216
quantity (pcs.):
1,268.50€ * 1,509.52€ incl. VAT
*Price plus VAT and shipping costs

Warranty: NieRuf-Garantie: Gilt bei sachgemäßer Verwendung für alle Mängel am Produkt, die Sie nicht selbst verschuldet haben. Gilt bspw. nicht bei Verschleiß. Weitere Details siehe AGBs Punkt 7 – 7.11. 24 Months

Delivery time: On demand

datasheet 3D model
All the information quoted in these resistance tables is based on industrial experience and the data of our material and compound manufacturers. NieRuf GmbH makes no guarantee, however, as to the correctness and completeness of this informations.

If materials are rated as ''limited suitability'', the time of impact has to be considered. At a long period of impact these materials can be heavily attacked or even destroyed. There- fore these parts are rated as wear parts and are not included in the standard warranty conditions.
Questions about the article?
Our colleague Meiko Holzinger will be happy to help:
Tel: +497143/9666-904
E-Mail: holzinger@nieruf.de
technical details
swing check valve DN300 ZR02 ANSI 150 stainless steel CF8M FKM
swing check valve DN300 ASME B16.5 / ANSI 150 made of stainless steel CF8M seal FKM for liquid and gaseous media
design: swing check valve
diameter: DN300
body material: stainless steel CF8M
disc material: stainless steel CF8M
seal: FKM
temperature: -15°C up to +200°C
connection: flange
flange: ASME B16.5 / ANSI 150
pressure range: 0 - 16 bar
media: liquid and gaseous media
tightness acc. to DIN EN 12266: leak rate A
option: without spring reset
installation position: direction of flow horizontal (disc must be free-hanging), vertical from below
product feature: short face to face
