SC02000008
piston-operated angle seat valve G 2" inch SC02 stainless steel
- Lead time
- in stock
- Express delivery*
Order in within by express delivery
Shipping on: Monday, 05. October
Guaranteed delivery until Tuesday, 06. October, 12 o'clock
Equipment
solenoid valve input: G 1/8" inch 230V AC KV06
€52.48 VAT included.
solenoid valve input: G 1/8" inch 24V DC KV06
€52.48 VAT included.
hexagon nipple 2" inch male stainless steel 316
€14.64 VAT included.
Questions about the article?
Our employee Richie Rost
will be happy to help you
NIERUF-SERVICE
piston-operated angle seat valve G 2" inch SC02 stainless steel
piston-operated angle seat valve type SC02 G 2" inch female thread DN50 closing against direction made of stainless steel 1.4408
| product | piston-operated angle seat valve |
|---|---|
| type | SC02 |
| manufacturer | NieRuf |
| design | angle seat valve with actuator |
| diameter | DN50 |
| connection | G 2" inch |
| type of connection | female thread |
| flow rate | 52,8 m³/h |
| function | NC - normally closed |
| working function | closing against flow direction |
| control | air min 3.0 to 10.0 bar |
| material | stainless steel 1.4408 |
| seal | PTFE |
| actuator | 100 mm |
| signal | with optical position indicator |
| media | liquid and gaseous media |
| temperature | -10°C up to +60°C |
| temperature media | -10°C up to +180°C |
| max. pressure | 0 - 9 bar |
| installation position | any position |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
piston-operated angle seat valve G 2" inch SC02 stainless steel
Article no.
: SC02000008
product:
piston-operated angle seat valve
type:
SC02
manufacturer:
NieRuf
design:
angle seat valve with actuator
diameter:
DN50
connection:
G 2" inch
type of connection:
female thread
flow rate:
52,8 m³/h
function:
NC - normally closed
working function:
closing against flow direction
control:
air min 3.0 to 10.0 bar
material:
stainless steel 1.4408
seal:
PTFE
actuator:
100 mm
signal:
with optical position indicator
media:
liquid and gaseous media
temperature :
-10°C up to +60°C
temperature media:
-10°C up to +180°C
max. pressure:
0 - 9 bar
installation position:
any position
Equipment
pipe bend (welded) 90° 60,3 x 2,0 stainless steel 1.4571
Lead time: in stock
reducing bush (welded) 76,1 x 2,3 to 60,3 x 2,0 stainless steel 1.4571
Lead time: 3 - 5 working days
