angle-type overflow valve 3/4" inch male type UV14 gunmetal 1,0 - 1,6 bar seal PTFE for liquid and gaseous media counter pressure compensated up to 4 bar
| product | angle-type overflow valve |
|---|---|
| type | UV14 |
| manufacturer | NieRuf |
| diameter | 3/4" inch male |
| connection | male thread BSP-P |
| leakage | 1 1/4" inch fm |
| seal | PTFE |
| media | liquid and gaseous media |
| temperature | -60°C to +225°C |
| range of adjustment | 1,0 - 1,6 bar |
| design | with an bellow, for counter pressure up to 4 bar |
| material | gunmetal Rg5 CC499K |
| installation position | preferably vertical |
| SIL - safety integrity level | SIL 3 |
| product feature | Counter-pressure compensated up to 4 bar. Adjusted by the customer in the corresponding spring range using the hand wheel. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
angle-type overflow valve 3/4" inch male UV14 gunmetal 1,0 - 1,6 bar
Article no.
: UV14020104
product:
angle-type overflow valve
type:
UV14
manufacturer:
NieRuf
diameter:
3/4" inch male
connection:
male thread BSP-P
leakage:
1 1/4" inch fm
seal:
PTFE
media:
liquid and gaseous media
temperature:
-60°C to +225°C
range of adjustment:
1,0 - 1,6 bar
design:
with an bellow, for counter pressure up to 4 bar
material:
gunmetal Rg5 CC499K
installation position:
preferably vertical
SIL - safety integrity level:
SIL 3
product feature:
Counter-pressure compensated up to 4 bar. Adjusted by the customer in the corresponding spring range using the hand wheel.
