fine-strainer 1/4" inch stainless Typ SZ05

SZ05000001
check valve DN 125 Stainless steel CF8M EPDM PN 10/16/25/40 DIN EN 1092-1 Form B 2
quantity (pcs.):
15.30€ * 18.21€ incl. VAT
*Price plus VAT and shipping costs

Delivery time: at stock

Express shipping:

Shipping on: Monday, 21. June
Guaranteed delivery until Tuesday, 22. June, 12 Uhr:
order within 2 Tage & 20 hours & 54 minutes via express shipping
datasheet
All the information quoted in these resistance tables is based on industrial experience and the data of our material and compound manufacturers. NieRuf GmbH makes no guarantee, however, as to the correctness and completeness of this informations.

If materials are rated as ''limited suitability'', the time of impact has to be considered. At a long period of impact these materials can be heavily attacked or even destroyed. There- fore these parts are rated as wear parts and are not included in the standard warranty conditions.
Questions about the article?
Our colleague Meiko Holzinger will be happy to help:
Tel: +497143/9666-904
E-Mail: holzinger@nieruf.de
technical details
fine-strainer 1/4" inch stainless Typ SZ05
fine strainer made of stainless steel 1.4408 1/4" inch female thread BSP PTFE-seal PN40 for liquid media up to +200°C
design: Y-strainer with draining cap
diameter: 1/4" inch
connection: female thread BSP
pressure: PN40
material: stainless steel 1.4408
mesh-material: stainless steel 1.4401
cap material: stainless steel 1.4408
seal: PTFE
media: liquid media
temperature: up to +200°C
mesh: 0,25 mm
installation position: horizontal or vertical position with descendant fluid
product feature: Y-strainer made of stainless steel, thread with draining cap and removable stainless steel filter, horizontal or vertical position.
fine-strainer 1/4" inch stainless Typ SZ05

Quickly and easily transfer the specification of our valves into your tender text or specification.
Just copy the text box below and paste it into your tender.

fine-strainer 1/4" inch stainless Typ SZ05
