SV17000208
diaphragm-safety valve 2" x 2" fm FKM SV17
- Lead time
- 3 - 5 working days
Certificates
Questions about the article?
Our employee Richie Rost
will be happy to help you
diaphragm-safety valve 2" x 2" fm FKM SV17
diaphragm-safety valve 2" x 2" fm SV17 seal FKM, set pressure 1,0 - 16,0 bar. for air
| product | diaphragm-safety valve |
|---|---|
| type | SV17 |
| manufacturer | NieRuf |
| diameter | 2" x 2" fm |
| d0 | 25,0 mm |
| connection | Female screw threaded BSP-P DIN EN ISO 228 |
| seal | FKM |
| media | for neutral, gaseous media without counter pressure. |
| temperature | -20°C up to +200°C |
| set pressure | 1,0 - 16,0 bar |
| design | with diaphragm |
| material | gunmetal CC499K |
| lifting | twist-type lifting mechanism |
| type test approval | TUV-SV-312 |
| requirements | acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2 |
| installation position | Safety valves with spring to be installed vertical with spring bonnet upwards standing. |
| SIL - safety integrity level | SIL 3 (on request) |
| product feature 1 | for air |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
diaphragm-safety valve 2" x 2" fm FKM SV17
Article no.
: SV17000208
product:
diaphragm-safety valve
type:
SV17
manufacturer:
NieRuf
diameter:
2" x 2" fm
d0:
25,0 mm
connection:
Female screw threaded BSP-P DIN EN ISO 228
seal:
FKM
media:
for neutral, gaseous media without counter pressure.
temperature:
-20°C up to +200°C
set pressure:
1,0 - 16,0 bar
design:
with diaphragm
material:
gunmetal CC499K
lifting:
twist-type lifting mechanism
type test approval:
TUV-SV-312
requirements:
acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2
installation position:
Safety valves with spring to be installed vertical with spring bonnet upwards standing.
SIL - safety integrity level:
SIL 3 (on request)
product feature 1:
for air
