ball diverter valve DN25 - 1" inch GK16 T Drilling inlet female thread 1 1/4" inch

GK16000006
quantity (pcs.):
834.76€ * 968.32€ incl. VAT
*Price plus VAT and shipping costs

Delivery time: 3-5 working days

datasheet 3D model
All the information quoted in these resistance tables is based on industrial experience and the data of our material and compound manufacturers. NieRuf GmbH makes no guarantee, however, as to the correctness and completeness of this informations.

If materials are rated as ''limited suitability'', the time of impact has to be considered. At a long period of impact these materials can be heavily attacked or even destroyed. There- fore these parts are rated as wear parts and are not included in the standard warranty conditions.
Questions about the article?
Our colleague Meiko Holzinger will be happy to help:
Tel: +497143/9666-904
E-Mail: holzinger@nieruf.de
technical details
ball diverter valve DN25 - 1" inch GK16 T Drilling inlet female thread 1 1/4" inch
ball diverter valve DN25 - 1" inch stainless steel 1.4408 GK16 lever T Drilling for liquid, gaseous media & cryogenic liquified gases
diameter: DN25 - 1" inch
connection: female thread 1 1/4" inch
Seal steam: PTFE
media: liquid, gaseous media & cryogenic liquified gases
temperature: -200°C up to +120°C - depending on working pressure and media
max. pressure: PN63
design: T Drilling
body material: stainless steel 1.4408
ball material: stainless steel 1.4404
ball seal: PTFE
length: 265mm
actuator: lever
actuator informations: connection inlet 1 1/4" DN32, outlet 1" DN25
installation position: To ensure the proper function of the ball diverter valves, they must be installed in such a manner that prevents impermissible static, dynamic or thermal loads from acting.
product description: Ball diverter valve with threaded connection made of stainless steel for the installation of two safety valves for the protection of containers designed for the storage of cryogenic gases. With T drilling.
