UV05020105

straightway form overflow valve 1" inch female UV05 gunmetal/brass 1,5 - 6,0 bar

€216.80*

€257.99 VAT included.

*Prices excl. VAT plus shipping costs

Lead time: 3 - 5 working days

Equipment

GF01300005

hexagon nipple 1" inch male stainless steel 316

€4.50*

€5.36 VAT included.

MM03000301

pressure gauge G 1/4" axial 50 mm steel MM03 0 - 10,0 bar

€10.60*

€12.61 VAT included.

Resistance check

Our employee <strong>Richie Rost</strong><br>will be happy to help you

Questions about the article?

Our employee Richie Rost
will be happy to help you

Tel: +49714396669-18

E-Mail: rost@nieruf.com

NIERUF-SERVICE

24 months warranty

Certified

Downloads

3D model

Datasheet

straightway form overflow valve 1" inch female UV05 gunmetal/brass 1,5 - 6,0 bar

straightway form overflow valve 1" inch female type UV05 made of gunmetal/brass pressure range 1,5 - 6,0 bar seal EPDM for liquid and gaseous media

product	straightway form overflow valve
type	UV05
manufacturer	NieRuf
diameter	1" inch female
connection	female thread BSP-P
seal	EPDM
media	liquid and gaseous media
temperature	-20°C to +120°C
range of adjustment	1,5 - 6,0 bar
design	straightway form
material	gunmetal/brass
installation position	any position
SIL - safety integrity level	SIL 2
product feature	High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

straightway form overflow valve 1" inch female UV05 gunmetal/brass 1,5 - 6,0 bar

Article no. : UV05020105
product: straightway form overflow valve
type: UV05
manufacturer: NieRuf
diameter: 1" inch female
connection: female thread BSP-P
seal: EPDM
media: liquid and gaseous media
temperature: -20°C to +120°C
range of adjustment: 1,5 - 6,0 bar
design: straightway form
material: gunmetal/brass
installation position: any position
SIL - safety integrity level: SIL 2
product feature: High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
