AV02020015
Globe valve DN 250 AV02 SG iron EN-JS1049 regulation cone
- Lead time
- 1 - 2 weeks
Equipment
joint set flange/flange DN250 - 10" Inch for flange PN16 steel
€77.11 VAT included.
flange seal DN250 PN16 273x329x2 Klingersil C 4400
€27.37 VAT included.
Questions about the article?
Our employee Richie Rost
will be happy to help you
Globe valve DN 250 AV02 SG iron EN-JS1049 regulation cone
Bellow-Globe valve DN 250 in straight through with bellow material SG iron EN-JS1049 for liquid and gaseous media authorization DVGW-Gas
| product | Globe valve |
|---|---|
| type | AV02 |
| manufacturer | NieRuf |
| diameter | DN250 |
| flange | flange acc. DIN EN 1092 |
| pressure | PN16 |
| seal | metal |
| media | liquid and gaseous media |
| temperature | -10°C up to +350°C - depending on working pressure |
| pressure range | 0 up to 16 bar - depending on operating temperature |
| design | straight through with bellow |
| body material | SG iron EN-JS1049 |
| material spindel unit | SG iron EN-JS1049 |
| handwheel | cast iron with epoxy-coating (non-rising) |
| plug | regulation cone |
| bellow | stainless steel 1.4571 |
| length | acc DIN EN 558 series 1 |
| authorized for | DIN DVGW-Reg. NG-4313AO 0772 |
| installation position | any position, spindle preferably vertical |
| product feature | Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN. At high differential pressures a balancing plug is necessary! |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Globe valve DN 250 AV02 SG iron EN-JS1049 regulation cone
Article no.
: AV02020015
product:
Globe valve
type:
AV02
manufacturer:
NieRuf
diameter:
DN250
flange:
flange acc. DIN EN 1092
pressure:
PN16
seal:
metal
media:
liquid and gaseous media
temperature:
-10°C up to +350°C - depending on working pressure
pressure range:
0 up to 16 bar - depending on operating temperature
design:
straight through with bellow
body material:
SG iron EN-JS1049
material spindel unit:
SG iron EN-JS1049
handwheel:
cast iron with epoxy-coating (non-rising)
plug:
regulation cone
bellow:
stainless steel 1.4571
length:
acc DIN EN 558 series 1
authorized for:
DIN DVGW-Reg. NG-4313AO 0772
installation position:
any position, spindle preferably vertical
product feature:
Stop valve - straight through with flanges and bellows seal additionally with non-rotation lock, flat lubricating nipple and position indicator as standard - CLOSED / OPEN. At high differential pressures a balancing plug is necessary!
Equipment
joint set flange/flange DN250 - 10" Inch for flange PN16 steel
Lead time: 3 - 5 working days
