AK05100016
Butterfly valve DN 300 PN16 AK05 EPDM lever
- Lead time
- 3 - 5 working days
Certificates
Questions about the article?
Our employee Richie Rost
will be happy to help you
Butterfly valve DN 300 PN16 AK05 EPDM lever
Butterfly valve DN 300 PN16 Wafer type body made of cast iron EN GJL-250 (GG25) with lever EPDM
| product | Butterfly valve |
|---|---|
| type | AK05 |
| manufacturer | NieRuf |
| diameter | DN 300 |
| nominal pressure | PN16 |
| max. working pressure | 16 bar |
| sleeves | EPDM |
| media | liquid and gaseous media |
| temperature | -10°C up to +110°C |
| design | Wafer type |
| body material | grey cast iron EN GJL-250 (GG25) |
| disc | stainless steel 1.4408 |
| actuation | lever |
| application | for ordinary usage |
| product feature | butterfly valve with high quality epoxyd coating body, stainless steel disc, vulcanized EPDM seal, long neck for isolate, direct construction after ISO 5211 for actuator, CE PED 97/23 certified. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Butterfly valve DN 300 PN16 AK05 EPDM lever
Article no.
: AK05100016
product:
Butterfly valve
type:
AK05
manufacturer:
NieRuf
diameter:
DN 300
nominal pressure:
PN16
max. working pressure:
16 bar
sleeves:
EPDM
media:
liquid and gaseous media
temperature:
-10°C up to +110°C
design:
Wafer type
body material:
grey cast iron EN GJL-250 (GG25)
disc:
stainless steel 1.4408
actuation:
lever
application:
for ordinary usage
product feature:
butterfly valve with high quality epoxyd coating body, stainless steel disc, vulcanized EPDM seal, long neck for isolate, direct construction after ISO 5211 for actuator, CE PED 97/23 certified.
